2/4Pcs MG945 Analog Metal Gear Airplane Fixed Wing Servo Motor High Speed Torque 180(Half Metal -180,4PCS)

Description

• Alternators

Alternators
Specification:
Product Model: MG945
Color: Black
Dimension : 40mm x 19mm x 43mm
Rotation Angle: 0-180 degrees
Operating Speed: 0.20sec/60 degrees (4.8V no load)
Operating Speed: 0.17sec/60 degrees (6.0V no load)
Stall Torque: 10.5kg/cm (4.8V)
Stall Torque: 13kg/cm (6V)
Operation Voltage : 4.8 - 7.2Volts
Operating Temperature: 0 - 55
Gear Material: Half Metal/All Metal
Dead Band Width: 5msec
Operating Mode: Analog
Accessories: Multi-arm, Fixing screws(AS the picture shows)
Connector Wire: 300mm(Brown: Negative; Red: Positive; Orange: Pulse Input)
Steering Gear Control:
The control of the steering gear generally requires a time base pulse of about 20ms, and the high level part of the pulse is generally the angle control pulse part in the range of 0.5ms~2.5ms.
The corresponding control relationship of the 180 degrees servo is as follows:
0.5ms---------------0 degrees;
1.0ms--------------45 degrees;
1.5ms--------------90 degrees;
2.0ms--------------135 degrees;
2.5ms--------------180 degrees
Please use a professional PWM Servo Controller to control the angle
Packing: 2 x MG945 Servo or 4x MG945 Servo for option(Including Accessories)
Torque : 13kg/cm
Model Number : MG945
Type : Servo Motor
Protect Feature : Totally Enclosed
Rotation Angle : 0-180 degrees
Operation Voltage : 4.8 - 7.2Volts
Gear Material : Half Metal/All Metal
